Slim Wall Pack
The Slim series is a wall pack luminaire with a thin modern look for today’s architecture. It also has adjustable mounting positions from 0 to 90 degrees. Improved and advanced chip technologies yield faster heat dissipation resulting in a much longer life while maintaining high luminous flux.
It has a high transmittance optical PC lens, that is anti-UV and fire resistant. It is well suited for harsher outdoor applications. There are a wide range of wattages and mounting options.
Wall Mount
Quick Summary
• Wattage: 12W, 40W, 30W, 50W, 80W, 100W, 120W
• Mounting: Wall Mount
• Ability to tilt 0-95 degrees
• Lumen : 1320lm, 3300lm, 4400lm, 5500lm, 8800lm, 1100lm, 13200lm
• Optics: 80 x100˚
• CCT: 4000K, 5000K
• CRI: Ra>80
• Voltage: 100-277V, 277-480V(100W only), 347-480V(40W only)
• Dimming: No Dimming, 0-10V Dimming(40W/80W/100W/120W only)
• Finish: Dark Bronze(Standard), White, Black
• IP Rating: IP65
• Certification: cETLus, CE & DLC
• Warranty: 6 Years
Downloads
- IES Files
- Data Sheet
- Warranty Statement
- Installation Guide
